Configurazione

Telaio:	Raze 29 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 130mm travel, Forward Geometry, one piece Monoblock upper link, Boost 12x148mm rear axle, tapered head tube, 73mm BSA bottom bracket, dedicated 1x drivetrain design, telescopic se
Materiale del telaio:	alluminio
Dimensione delle ruote:	29″
Colore:	Black – Dirty white
Forcella:	RockShox 35 Gold 29 RL, 150mm, Solo Air, tapered steerer tube, Boost 15x110mm axle, 35mm steel stanchions, 44mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload
Ammortizzatore:	Fox Float DPS LV EVOL Performance, 205×57.5mm. Settings: rebound, 3-position compression adjustment (Open/Mid/Lock), air preload. Trunnion top mount, 30x8mm bottom bushings
Corsa sospensione:	150 mm
Freni:	Sram Level T, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad
Dischi freno:	180mm / 180mm
Leve freno:	Sram Level T, Direct Link actuation, tooled reach adjust, lever pivot bushings
Serie sterzo:	Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41×30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º
Attacco manubrio:	Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore
Manubrio:	ONOFF Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barboreupsweep, 31.8mm barbore
Manopole:	Onoff Twin, 1lock-on, 135mm
Sella:	MDK series PU 2023

Reggisella:	Onoff Pija dropper internal, diameter 31.6mm, S size: 405×95-125mm, M size 458×120-150mm, L size: 498×140-170mm, XL size: 498×140-170mm
Guarnitura:	Sram SX Eagle, Boost, DUB axle, Direct Mount chain ring, S/M size: 170mm, L/XL size: 175mm, 32T, steel, X-Sync 2
Movimento centrale:	Sram DUB BSA, sealed bearings, 73mm
Cambio posteriore:	Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1
Comandi cambio:	Sram Trigger SX Eagle, 12s, X-Actuation 1:1
Cassetta:	Sram PG-1210, 11-50T, 12s
Catena:	Sram SX Eagle, 12s, Powerlock
Copertone anteriore:	Maxxis Dissector 29×2.4 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead
Copertone posteriore:	Maxxis Aggressor 29×2.3, tubeless ready, dual compound, Exo protection, 60TPI, folding bead
Mozzo anteriore:	Formula DC711, Boost 15x110mm, sealed bearings, IS 6 bolts
Mozzo posteriore:	Formula DHT148 Boost 12x148mm, sealed bearings, IS 6 bolts
Raggi:	CN round stainless steel
Cerchi:	MDK-EP1 29, 30mm internal width, tubeless ready, 32 spokes
Pedali:	non incluso nella fornitura
Altri dettagli:	Derailleur hanger: Sram UDH
